WPDKZ Single Speed Cast Iron Worm Gearbox — WP Series

Industrial drive engineers occasionally face a specification that demands three simultaneous features from a single gearbox: mounting via a circular flange (Z-type), a direct IEC motor connection without coupling (D-type), and a hollow bore output for direct shaft insertion (K-type). Individually, each feature has its dedicated WP-series solution. Combined, they describe the WPDKZ Single Speed Cast Iron Worm Gearbox — the most feature-rich unit in the WP single-speed range, serving vessel-nozzle-mounted motorised shaft-mount drives across the pharmaceutical, chemical processing, and food manufacturing sectors globally.

✉ Request a Quote  |  About Ever-power

■ D+K+Z: Three Features, One Precision Cast Iron Unit

The WPDKZ is the pinnacle of the WP single-speed range feature integration: D-type IEC motor flange eliminates the coupling on the input, K-type hollow bore eliminates the coupling on the output, Z-type flange housing eliminates the mounting bracket. Three problems solved, one part ordered.

■ IEC Motor Flange (D) + Top-Entry (T-Input): Direct Overhead Motor Mount

The D-type IEC flange is positioned at the T-input location (top), allowing direct overhead motor mounting. Motor drops onto flange, four bolts, drive is complete. For ceiling-height-limited process environments, this is the most space-efficient motorised drive configuration possible.

■ Hollow Bore (K) Output: Shaft Passes Directly Through

The K-type hollow bore output eliminates the output coupling entirely. The driven shaft (agitator, screw, paddle) passes through the bore and is secured by key and keyway — no external shaft protrusion, no exposed coupling, minimum contamination surface.

■ Z-Flange Housing: Vessel/Structure Direct-Bolt

The Z-type flange housing bolts directly to vessel nozzles, structural flanges, and wall plates — eliminating the foot-mount bracket fabrication that adds to project cost and schedule.

■ D-Split Housing (D-type) for Field Maintainability

The D-type housing is inherently a split housing design. The cover can be removed while the motor remains mounted (D-flange) and the agitator shaft remains in the K-bore — worm wheel access in the most confined vessel-top installation imaginable.

■ Compact Size Range 50–135: Precisely Targeted at Small Vessel Applications

The 7 standard sizes (50–135 mm) cover the 6 Nm to 690 Nm output range that describes the majority of small-to-medium vessel, reactor, and pharmaceutical mixing drives.

⚒ Motorised Vessel Hollow-Shaft Agitators

The WPDKZ achieves the most compact possible motorised vessel agitator drive: Z-flange to vessel nozzle, D-IEC motor overhead, K-hollow bore onto agitator shaft — complete drive in one unit, zero external hardware.

⚔ GMP Pharmaceutical Vessel Drives

Pharmaceutical manufacturing vessels require the minimum number of external surfaces and coupling interfaces for contamination control. The WPDKZ triple-feature design minimises exposed drive hardware to its absolute minimum.

☵ Chemical Reactor Shaft-Mount Agitators

Chemical reactors with top-entry flange nozzles, overhead motors, and agitator shaft-mount connections represent the core WPDKZ market — a single unit for a complex engineering requirement.

⚊ Compact Panel-Mounted Equipment

Control panel and wall-mounted compact process drives that require flange mounting, direct motor connection, and hollow bore shaft output in a small package (sizes 50–135) use the WPDKZ as their single-unit solution.

⚛ Food & Beverage CIP-Compatible Drives

Food and beverage process vessels requiring CIP (clean-in-place) compatible drive units choose the WPDKZ for its minimum exposed surface design and direct motor mounting that eliminates corrosion-prone coupling hardware.
